5000W Pure Sine Wave Solar Hybrid Inverter 80A Solar Panel Charger and AC Charger All in One for Ma



US $900.00Original Price : US $1500.00 (40%)

Best Offer 5000W Pure Sine Wave Solar Hybrid Inverter 80A Solar Panel Charger and AC Charger All in One for Ma with FREE Worldwide Shipping!

 4.71

Buy on AliExpress

Related Products :

Product description

[4000689137726]

5000W Pure Sine Wave Solar Hybrid Inverter MPPT 80A Solar Panel Charger and AC Charger All in One for Max 4000W 500V Solar Input Overview: Battery Voltage:48Vdc AC Charger Input :230VAC 60A Solar Charger Input:4000W 500V MPPT Inverter:3200W Pure Sine Wave 230VAC 50Hz/60Hz This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications Feature: Pure sine wave inverter Configurable input voltage range for home appliances and personal computers via LCD setting Configurable battery charging current based on applications via LCD setting Configurable AC/Solar Charger priority via LCD setting Compatible to mains voltage or generator power Auto restart while AC is recovering Overload/ Over temperature/ short circuit protection Smart battery charger design for optimized battery performance Cold start function
Parameter: Mode Name VM-3KVA VM-5KVA Rated Power 3200VA/3200W 5000VA/5000W INPUT Voltage 230VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC(For Home Appliances) Frequency Range 50Hz/60Hz(Auto sensing) OUTPUT AC Voltage Regulation(Batt mode) 230VAC plusmn 5% Surge Power 6400VA 10000VA Efficiency(Peak)PV to INV 97% Efficiency(Peak)Battery to INV 94% Transfer Time 10 ms(For Personal Computers);20 ms(For Home Appliance) Waveform Pure sine wave BATTERY@AC CHARGER Battery Voltage 24VDC 48VDC Float Charging Voltage 27VDC 54VDC Ovrecharge Protection 33VDC 63VDC Maximum Charge Current 80A 60A SOLAR CHARGER Maximum PV Array Power 4000W 5000W MPPT Range@Operating Voltage 120~450VDC Maximum PV Array Open Circuit Voltage 500VDC Maximum Charging Current 80A Maximum Efficiency 98% PHYSICAL Dimension, D x W x H (mm) 100x300x440 Net Weight 9 10 Communication Interface USB/RS232/WIFI OPERATING ENVIRONMENT Humidity 5% to 95% Relative Humidity (Non-condensing) Operating Temperature -10degC to 50degC Storage Temperature -15degC to 60degC Product show:
